FAA Chart: VFR TAC CHICAGO

The FAA Chicago Terminal Area Chart shows the Chicago area at 1:250,000, twice the scale of a sectional, so one inch covers about 3.43 nautical miles. The Chicago panel spans about 41.4°N to 42.6°N and 89.2°W to 86.8°W. The Chicago TAC area falls on the Chicago sectional.

Pilots working in or near the Chicago Class B or Class C airspace get added detail on airspace boundaries, airports, navaids, obstructions and the landmarks used as VFR checkpoints. The FAA prints the Chicago VFR Flyway Planning Chart on the back of this chart.

Rolled charts are printed on heavy paper with the entire image on one side. They ship rolled in a cardboard tube.

Rolled charts are designed for hanging on a wall or framing.

Lifestyle images may not be to scale. Frame not included.

About Current & Next Editions: Orders for the current edition ship immediately. Orders for the next edition will not ship until that edition becomes available. The current edition is dated October 29 – December 23, 2026. The next edition is dated December 24, 2026 – February 17, 2027 and ships December 15. Current edition and next edition orders must be shipped separately. If you combine these on one order, you may be charged for two shipments.
